Control Valve Pipe Installation . understanding proper installation and application of the steam control valve is essential to experiencing maximum value. make sure the valve, flanges, and pipe are all compatible with the correct pressure class and materials specified before installation. For example, assume a 3 inch. • always match the pipe size to the heat transfer inlet connection. if a control valve is mounted at a certain height, a permanent platform or walkway. set control valve in the horizontal line of piping in an accessible location with the arrow on the side of the valve body in the direction of fluid flow. See drawings on page 1. pipe size after the control valve. install valve with the proper ports as inlets and outlets. Upright positioning of control valve is preferable for ease of maintenance. mistakes in installation can manifest in valve leakage or failure, compromising the integrity of the entire piping system.
